Telescopic Boom Lifts

Lift, Boom 60' Straight

Image for reference only
Actual item may look different
Click on image for larger view

Click on above thumbnails for alternate view

Manufacturer: JLG

Model: 600S

Quantity:

Additional Information

Platform Height - 60 ft
4 wheel drive
Max Horizontal Reach - 49 ft 9 in
Platform capacity - 500 lbs
Platform size - 8 ft x 3 ft
Overall Length - 30 ft 8 in
Overall Width - 8 ft 2 in
Overall Height-Mast Lowered - 8 ft 9 in
Wheelbase - 10 ft 2 in
Ground clearance - 13 in
Driveable at full height
_____________________________________________________
Tier 4i Final
S-60J
Measurements
Working height max.(1) 66 ft 10 in
Platform height max. 60 ft 10 in
Horizontal reach max. 40 ft 6 in
Platform length (8 ft/6 ft) 3 ft/2 ft 6 in
Platform width (8 ft/6 ft) 8 ft/6 ft
Height - stowed 8 ft 10 in
Length - stowed 31 ft 10 in
Length - storage/transport (jib tucked under) 23 ft 6 in
Width 8 ft 2 in
Wheelbase 8 ft
Ground clearance - center 1 ft 10 in
Height under counterweight 3 ft 4 in
Lift capacity max. - unrestricted 660 lb 300 kg
Number of Platform Occupants 2
Platform rotation 160
Jib length 6 ft
Vertical jib rotation (up/down) 130
Turntable rotation 353
Turntable tailswing 5 ft 2 in
Drive speed - stowed 3mph 4.82 km/h
Drive speed - raised 0.68mph 1.1 km/h
Gradeability - stowed(2) 45%
Tilt sensor activation (front to back/side to side) 5 / 5
Turning radius - inside/outside 8 ft 1 in/ 18 ft 5 in
Tires 315/55D20
Power Diesel
Hydraulic tank capacity 21 gal 79 L
Fuel tank capacity 30 gal 114 L
Weight(3) and Floor Loading(4)
Weight 16,650 lb 7,550 kg
Tire contact pressure 85 psi 585 kPa
Occupied floor pressure 215 psf 10.28 kPa
Sound and Vibration Levels
Sound Pressure level (ground workstation) 83 dBA
Sound Pressure level (platform workstation) 77 dBA
Vibrations < 2.5m/s
Gradeability 30 %
Dual Fuel Engine
