Riding Rollers

Roller, Ride-On 54" Smooth/Pad Single Drum

Image for reference only
Actual item may look different
Click on image for larger view

Click on above thumbnails for alternate view

Manufacturer: Sakai Bomag

Model: SV204T BW145PDH-3

Quantity:

Additional Information

SAKAI SV204T:
Dimensions:
Length - 165.1"
Height - 74.8"
Height - with ROPS / FOPS - 108.3"
Width 60.8"
Inside Turning Radius - 109.5"
Steering Angle - 35
Weights:
Operating Weight 11,170 lbs. with ROPS / FOPS
Engine:
Engine Make - Deutz
Fuel Type Diesel
Application Both
Nominal Amplitude 0.067 / 0.033"
Vibration Frequency 2,040 / 2,040 vpm
Centrifugal Force Range 22,500 / 11,250 lbs.
______
BOMAG BW145:
Operating Weight 10472 LBS
Horsepower 74HP
Emission Rating Tier 4 Final
Roller Width 56.1 in
ENGINE
Engine Make/ModelDeutz / TD 2.9 L04
Net Torque 192LBF/FT
Rated Speed 2400rpm
Displacement 177in3
DRIVETRAIN
Transmission Type Hydrostatic
Max Forward Speed 6.2mph
Tire Size 12.5 -20
Number of Tires 2
Tire Type 12PR
Fuel Tank Capacity 29 gal
Length 14ft 4in
DIMENSIONS
Width 5ft 1in
Height - ROPS / No ROPS 8ft 11in / 5ft 2in
Wheelbase 7ft 4in
Overhang - Left / Right 2.6in / 2.6in
Ground Clearance 12.6in
STEERING
Steering Axle Articulation
Steering Angle 35
Oscillation Angle 12
Turning Radius - Inside
VIBRATORY SYSTEM
Vibratory Frequency (stage I / stage II) 1,860 vpm / 2,280 vpm
Amplitude (stage I / stage II) 0.067in / 0.031in
Centrifugal Force (stage I / stage II) 17,985 lbf / 12,589 lbs
Gradeability48% (w/ vibration) / 51% (w/o vibration)

* Please call us with any questions about our roller ride on 54 inch smooth/pad single drum rentals in Los Angeles, Orange, San Bernardino, San Diego, and Riverside Counties, Santa Fe Springs, Sun Valley, or Corona California.
