Image for reference only
Actual item may look different
Click on image for larger view

Click on above thumbnails for alternate view

Manufacturer: John Deere

Model: 210

Quantity:

Additional Information

John Deere 210G
Mid-Size Excavator
DRIVELINE
Emission Rating Tier 4
Engine Manufacturer John Deere Power Tech
Number Of Cylinders 6
Displacement, ltr (Inches ) 6.8 (415)
Rated speed, rpm 2000
Engine Output - Net, kW (hp) 119 (159)
Number Of Carrier Rollers - Each Side 2
Number Of Track Rollers - Each Side 7
Track Shoe Width, mm (inches) 800 (32)
DIMENSIONS
Transport Length Mono Boom, mm (ft/in) 9530 (31 ft 3 in)
Transport Height - Maximum, mm (ft/in) 3010 (9 ft 11 in)
Overall Undercarriage Width, mm (ft/in) 3020 (9 ft 11 in)
Track Length On Ground, mm (ft/in) 3350 (11 ft )
Overall Undercarriage Length, mm (ft/in) 4170 (13 ft 8 in)
Tailswing Radius, mm (ft/in) 2890 (9 ft 6 in)
Ground Clearance, mm (inches) 450 (17.72)
Width over fixed tracks, mm (ft/in) 3020 (9 ft 11 in)
Track Gauge, mm (ft/in) 2220 (7 ft 3 in)
Digging Reach - Mono Boom, mm (ft/in) 9920 (32 ft 7 in)
Ground Level Reach - Mono Boom, mm (ft/in) 9750 (32 ft )
Dig Height - Mono Boom, mm (ft/in) 10040 (32 ft 11 in)
Dump Height - Mono Boom, mm (ft/in) 7180 (23 ft 7 in)
Dig depth - 2.44m / 8'ft flat bottom, mm (ft/in) 6500 (21 ft 4 in)
Dig Depth - Mono Boom, mm (ft/in) 6670 (21 ft 11 in)
Standard Arm, mm (ft/in) 2910 (9 ft 7 in)
CAPACITIES
Fuel Tank, ltr (gallons (US)) 403 (106.5)
Hydraulic Tank, ltr (gallons (US)) 135 (35.7)
Number Of Batteries 2
Voltage, V 24
PERFORMANCE
Ground Bearing Pressure, kPa (PSI) 37.7 (5.47)
Swing Speed, rpm 13.3
Swing Torque, kNm (lbf / ft) 68.9 (50662)
Travel Speed - High, kph (mph) 5.5 (3.4)
Tractive Force, kN (lbf) 202.9 (45636)
Arm Tearout, kN (lbf) 114 (25628)
Bucket Breakout, kN (lbf) 158 (35520)
Gradeability, % 70
End lift - 7.5m Reach, kg (lbs) 4420 (9520)
Side lift - 7.5m Reach, kg (lbs) 2730 (5860)
Total Flow, lt/min (gallons (US) / min) 424 (112)
Bucket Pressure, bar (PSI) 343 (4975)
Boost Pressure, bar (PSI) 380 (5511)
WEIGHTS
Operating Weight, kg (lbs) 23161 (51061)
___
PC210 JOHN DEERE
Mid-Size Excavator
Net Power: 119 kW (159 hp)
Max. Digging Depth: 6.67 m (21 ft. 11 in.)
Operating Weight: 23 560 kg (51,940lb.)
____
Hitachi ZX210LC-6
Net Power: 163.6 hp
Max Dig Reach: 32' 7"
Operating Weight: 50,265 lbs
Max Dig Depth: 21' 11"
