Excavators

Excavator, 8,500# Electric

Image for reference only
Actual item may look different
Click on image for larger view

Click on above thumbnails for alternate view

Manufacturer: Takeuchi

Model: TB240e

Quantity:

Additional Information

TB240e
OPERATING PERFORMANCE
Operating Weight Canopy 8,570 lbs
Maximum Digging Depth 11 ft 4.3 in
Maximum Dump Height 12 ft 6.7 in
Maximum Reach 18 ft 2.3 in
Bucket Breakout Force 9,959 lbs
ENGINE
63hp
State of the art lithium battery
Proprietary Lithium WhisperTech Battery System rated for 2,000 charge cycles, after which it retains 80% of its original capacity.
9 hour run time at 65% load
Charges from empty to full in 10 hours (220 outlet)
UNDERCARRIAGE
Traction Drive Type Planetary Reduction w/ Automatic Shift Down
Parking Brake Spring Applied, Hydraulically Released
Track Roller Type Permanently Sealed, Triple Flanged Rollers
Track Rollers 4 per side
Track Width 13.8 in (350 mm)
Track Ground Contact Length 5 ft 5.1 in (1,653 mm)
Ground Pressure 3.9 psi (26.2 kPa)
Maximum Travel Speed
Low Range 1.7 mph (2.7 km/hr)
High Range 3.0 mph (4.9 km/hr)
HYDRAULIC SYSTEM
Pump Type Two Piston Pumps w/ Two Gear Pumps
Total Hydraulic Flow 30.6 gal / min (115.8 L / min)
Primary Auxiliary Hydraulic Flow 17.1 gal / min (64.9 L / min)
System Operating Pressure 3,481 psi (24.0 MPa)
Hydraulic Reservoir Capacity 9.2 gal (35.0 L)
Hydraulic System Capacity 17.7 gal (67.0 L)
DIMENSIONS
Maximum Dig Depth 11 ft 4.3 in (3,462 mm)
Maximum Dump Height 12 ft 6.7 in (3,828 mm)
Maximum Reach Ground Level 18 ft 0 in (5,500 mm)
Maximum Vertical Dig Depth 8 ft 9.2 in (2,673 mm)
Overall Width 5 ft 8.5 in (1,740 mm)
Transport Height 8 ft 0 in (2,445 mm)
Transport Length 16 ft 6 in (5,020 mm)
Ground Clearance 11.6 in (295 mm)
Dozer Blade Height 15.5 in (395 mm)
Independent Boom Swing Angle 76 Left / 58 Right
Minimum Front Swing Radius (Straight) 6 ft 8.2 in (2,037 mm)
Minimum Front Swing Radius (Offset) 5 ft 4 in (1,626 mm)
Tail Swing Radius 4 ft 5.1 in (1,350 mm)

Also check the following item(s) related to the above:

Bucket, 18" Q/C EX 6K-8K

* Please call us with any questions about our excavator 8 500 electric rentals in Los Angeles, Orange, San Bernardino, San Diego, and Riverside Counties, Santa Fe Springs, Sun Valley, or Corona California.
